4G Mobile DVR Designed for Passenger Coaches Buses Taxis and Dangerous Goods Vehicles with Stable Performance and Easy Operation
جزئیات محصول:
| محل منبع: | شنژن |
| نام تجاری: | Oxiang /OEM |
| گواهی: | CE.RoHS,FCC |
| شماره مدل: | MD264 |
|
اطلاعات تکمیلی |
|||
| شبکه: | وای فای 2.4 گیگاهرتز (IEEE 802.11 b/g/n) | چشمک زدن LED قرمز: | روشن شود، در انتظار اتصال WiFi |
|---|---|---|---|
| نوع قدرت: | باتری قابل شارژ 18650 یا سیم سخت AC12V-24V | مصرف: | حالت کار: 170mA حالت آماده به کار: 200μA |
| وزن: | 600 گرم | محدوده وانت: | 5 متر |
| رطوبت کاری: | <95% | تابع پیام: | از عملکرد خروج پیام پشتیبانی می کند |
| شاتر: | 1/25 ~ 1/100، 000 در ثانیه | رطوبت نسبی: | 85% غیر متراکم |
| فاصله IR: | 3 متر | سنسور تصویر: | SC2335/SC233A |
| زاویه افقی: | زاویه افقی 140 | زاویه تشخیص: | 110 درجه |
| تابع: | 3G/4G/GPS/WiFi | قدرت: | DC12V/2A |
| تنظیم تصویر: | پشتیبانی از آینه پشتیبانی HD/SD | میزان ضد آب: | IP55 |
| دوربین: | 1 مگا پیکسل، OV9732 (125 درجه زاویه دید) | زاویه: | 130 درجه |
| اندازه صفحه نمایش: | 7 اینچ | وضوح ورودی دوربین: | AHD1080P/720p/CVBS |
| نوع سنسور: | شمارش ویدیو، دقت 98 درصد | بعد میزبان: | 200 (L) x187 (W) x62 (H) میلی متر |
| فشرده سازی: | H.265 | ورودی ولتاژ: | سازگاری با ولتاژ 8 تا 36 ولت فوق عریض |
| پشتیبانی نرم افزاری: | CMSV6 و پلت فرم خصوصی ما | گارانتی: | 12 ماه |
| SDK: | SDK رایگان برای توسعه دوم | دانلود WIFI: | پشتیبانی کنید |
| رابط عملیاتی: | رابط کاربری گرافیکی (منوی OSD) | سفارشی سازی: | بله |
| ضد آب: | IP69k | ضد شوک: | ضد لرزش دوگانه |
| توابع: | شمارنده افراد، 3G، GPS، سنسور G، UPS | ||
| برجسته کردن: | 4G mobile DVR for passenger coaches,4G mobile DVR for buses with stable performance,4G mobile DVR for dangerous goods vehicles,4G mobile DVR for buses with stable performance,4G mobile DVR for dangerous goods vehicles |
||
توضیحات محصول
4CH 4G WiFi HDD/SSD MDVR specification sheet
Model:OX-MD264
1.1 Product features
This series of products is a fully functional Hard Disk Driver 4G mobile DVR designed for the mobile surveillance market. Supports wide power voltage input, supports high-capacity HDD/SSD and TF card recording; Use professional and reliable aviation plug connector; High appearance, enough materials, good heat dissipation; The device has powerful functions, rich interfaces and low power consumption; Simple installation, easy operation, and extremely stable; widely used in passenger Coach, buses, taxis, school buses, logistics vehicles, dangerous goods vehicles, Sedan cars, ships, etc.
The detailed features are as follows:
- Industrial design, stable and reliable, easy to install
- Video adopts the international mainstream H.265 encoding format, and the audio adopts G711a encoding. It can support up to 4 channels.
- Professional vehicle power supply, can adapt to 8 to 36V ultra-wide voltage input, with multiple protection circuits such as overload/short circuit/reverse connection
- Highly reliable aviation plug input and output interface, easy to install and plug, and stronger Vandal-proof performance
- Support 4 channels of video and audio input, frame rate and image quality are adjustable
- Support 1x2.5inch HDD/SSD +1xTF Card Storage
- Built-in Farad capacitor. The video content has power-off protection function
- Support video loss alarm function
- Independent delay Power shutdown, can support the system to continue running after the vehicle is turned off, the delay time can be set by yourself
- Supporting CMS client platform, providing multiple functions such as playback, analysis, management, etc
- Support HDD/SSD, TF card and U disk to upgrade firmware, support network remote firmware upgrade.
- Supports 2 USB ports, the front can be connected to a USB drive to export videos or upgrade firmware, and the back can be connected to a fireproof box to backup videos
- Support 8 x IO alarm input, 2 x IO alarm output
- Support 2 x RS232 and 1 x RS485
- Insert the intercom handle for two-way communication between the platform and the device
- Support pulse vehicle speed. Optional
- Support 4G, GPS, LAN(RJ45)
- Optional WiFi function
